Lightning Series Fiber Laser (500-6000 W)
Laser sourceFuente láser

Lightning Series Fiber Laser (500-6000 W)

Hisense Laser (Hyperline) · Beijing headquarters; production base in Tianjin · Lightning series

Compact, lightweight continuous-wave fiber laser source for cutting, welding, cladding, cleaning and precision processing. Uses fourth-generation pump source with 35-40% electro-optical efficiency.

Key specificationsEspecificaciones clave

Laser powerPotencia láser
0.5-6 kW0.5-6 kW
Power supplyAlimentación
380V380V

Ranges cover the models in this family. Values marked "up to" are the family maximum.Los rangos cubren los modelos de la familia. Los valores con "hasta" son el máximo de la familia.

7 models in this family:7 modelos en esta familia: 500 W, 1000 W, 1500 W, 2000 W, 3000 W, 6000 W, Lightning Plus 1500-6000 W

Get a quote for this machineCotizar esta máquina

Price depends on configuration, destination and delivery scope. A sourcing specialist replies by email in English or Spanish. Free to request.El precio depende de la configuración, el destino y el alcance de entrega. Un especialista responde por correo en inglés o español. Solicitar es gratis.

ApplicationsAplicaciones

Materials and workMateriales y trabajo
Sheet metal processingPrecision processing3D printingLithium-ion battery processingCladding and cleaning
IndustriesIndustrias
Sheet metal fabricationBattery manufacturing
Manufacturer's feature listCaracterísticas según el fabricante
  • Fourth-generation pump source
  • Forced water cooling
  • Multiple anti-reflection structure for high-reflection materials
  • Optional fiber output

SpecificationsEspecificaciones

Specifications as printed by Hisense Laser (Hyperline)
Power range500 W to 6000 W
ModelsBFL-CW500 / CW1000 / CW1500 / CW2000 / CW3000 / CW6000
Wavelength1080 +/-10 nm
Output connectorQBH
Fiber core diameter14 um (500 W) / 20 um (1000 W) / 25 or 50 um (1500 W) / 34 or 50 um (2000 W, 3000 W) / 50 um (6000 W), or customized
Modulation frequency0-5 kHz
Voltage220 +/-20 V AC, 50/60 Hz (500-2000 W); 380 +/-20 V AC (3000 W, 6000 W)
Dimensions (500-1500 W)80 x 402 x 296 mm
Dimensions (6000 W)93 x 482 x 806 mm

Source: Hisense Laser (Hyperline) catalog, page 13. Manufacturer statement, not independently tested. Final values are confirmed in the quote.Fuente: catálogo de Hisense Laser (Hyperline), página 13. Declaración del fabricante, sin prueba independiente. Los valores finales se confirman en la cotización.

ConfigurationsConfiguraciones

Models the manufacturer lists in this family. Choose one above to include it in your quote request, or leave it open and describe your parts.Modelos que el fabricante publica en esta familia. Elija uno arriba para incluirlo en su solicitud, o déjelo abierto y describa sus piezas.

500 W1000 W1500 W2000 W3000 W6000 WLightning Plus 1500-6000 W
Laser powerPotencia láser
0.5-6 kW0.5-6 kW
