Weitusai (VTS) · Dezhou, Shandong · WTS-S series
Dual-belt sanding machine that deburrs, removes oxide and grinds flat parts in one pass. Models S600, S800 and S1000.
Ranges cover the models in this family. Values marked "up to" are the family maximum.Los rangos cubren los modelos de la familia. Los valores con "hasta" son el máximo de la familia.
3 models in this family:3 modelos en esta familia: WTS-S600, WTS-S800, WTS-S1000
Price depends on configuration, destination and delivery scope. A sourcing specialist replies by email in English or Spanish. Free to request.El precio depende de la configuración, el destino y el alcance de entrega. Un especialista responde por correo en inglés o español. Solicitar es gratis.
| Processing width | 600 / 800 / 1000 mm |
|---|---|
| Processing thickness | 1-110 mm |
| Sanding belt size | 600, 800, 1000 x 1730 mm |
| Feeding speed | 0-20 m/min |
| Main motor power | 7.5 kW x2 (S600, S800), 11 kW x2 (S1000) |
| Total rated power | 17 / 17 / 24 kW |
| Control system | PLC |
| Power supply | AC380V/50Hz |
| Machine weight | 1165 / 1410 / 1542 kg |
| Dimensions (S1000) | 1850 x 1500 x 1980 mm |
Source: Weitusai (VTS) catalog, page 13. Manufacturer statement, not independently tested. Final values are confirmed in the quote.Fuente: catálogo de Weitusai (VTS), página 13. Declaración del fabricante, sin prueba independiente. Los valores finales se confirman en la cotización.
Models the manufacturer lists in this family. Choose one above to include it in your quote request, or leave it open and describe your parts.Modelos que el fabricante publica en esta familia. Elija uno arriba para incluirlo en su solicitud, o déjelo abierto y describa sus piezas.
